Stationary Foot Pump Scissor Table MK-B MK-B
Stationary Foot Pump Scissor Table【MK-BSeries】
※ Heavy duty design
※ New design to meet norm EN1570.
※ Foot operated lifting, hand operated lowering.
※ Suitable for place without or far away from electricity.
※ Widely load range from 250 kg to 1000 kg.
Model | MK-B25C | MK-B50C | MK-B75C | MK-B100C | MK-B30D |
Capacity (Kg) | 250 | 500 | 750 | 1000 | 300 |
Platform Size LXW (mm) | 830x500 | 1010x520 | 1010x520 | 1010x520 | 1010x520 |
Base Frame Size LXW (mm) | 820X500 | 913X520 | 913X520 | 913X520 | 913X520 |
Lowered Height (mm) | 152 | 152 | 152 | 160 | 240 |
Raised Height (mm) | 715 | 800 | 800 | 800 | 1380 |
Foot Pedal Without Rated Load | 30 | 58 | 78 | 80 | 60 |
Foot Pedal with Rated Load | 50 | 62 | 82 | 85 | 63 |
Net Weight (Kg) | 73 | 115 | 115 | 122 | 135 |
